Nelson 656HVY PVC Hi-Vis COMMERCIAL RAIN GEAR Bib Pants – ANSI Class E / EN 20471

From $160.00

Material
500 gsm oil-resistant PVC, hi-vis yellow
Construction
Mostly one-piece PVC with no side seam; the remaining seams are double welded. Built to withstand spray from any direction, not just rain
Features
Elastic waistband, low back, internal reinforced chest pocket, 2-inch marine-grade reflective tape, ANSI Class E / EN 20471 Class 1
Best for
Road crews and highway workers, pressure washing contractors, municipal/public sector workers (parks, sanitation, utilities) needing ANSI-compliant hi-vis rain gear
Weight: 1.5kg / 3.3lbs (+/-)
Model: M 5ft 9in / 167lbs (76kg)
Add to Cart
Nelson 656HVY PVC Hi-Vis COMMERCIAL RAIN GEAR Bib Pants ANSI Class E
Nelson 656HVY PVC Hi-Vis COMMERCIAL RAIN GEAR Bib Pants - ANSI Class E / EN 20471
From $160.00
FREE STANDARD SHIPPINGEST. 1966100% SECURE CHECKOUT
Guaranteed Safe Checkout

Men’s clothing size guide
Raglan Sleeve Jacket Sizing Example
Raglan Sleeve Jacket Sizing Example

1. Measure your chest

Measure around the fullest part of your chest keeping the measuring tape under your shoulder blades.

2. Measure your waist

Measure around the natural waist (smallest part of your waist).

Our sizing is designed for layering underneath.

Jackets, Vests & Mid Layers XS S M L XL 2XL 3XL 4XL 5XL 6XL
Chest in CMs 89 95 100 105 110 115 120 125 130 135
Chest in Inches 34 38 40 42 44 46 48 50 52 54
Euro Chest 44 46 48 50 52 54 56 58 60 62
Pants & Bibs XS S M L XL 2XL 3XL 4XL 5XL 6XL
Waist in CMs 77 82 87 92 97 102 109 114 119 124
Waist in Inches 30 32 34 36 38 40 42 44 46 48
EU Waist 44 46 48 50 52 54 56 58 60 62
Inside Leg in CMs 68 70 71 71 73 75 75 76 76 76
Inside Leg in Inches 26 27 28 28 29 30 30 31 31 31

Nelson 656HVY bib pants are medium-weight hi-vis rain gear that conforms to ANSI Class E and EN 20471 Class 1. They’re made from 500 gsm PVC in hi-vis yellow, so you stay visible on dark, wet roadsides and in poorly lit work areas.

Most of each leg is cut from one piece of PVC, with no side seam, and the few seams that remain are double welded. Fewer seams means fewer places for water to get in and fewer weak points, so the bib pants last longer on construction and wash jobs.

An elastic waistband and a low back make the 656HVY comfortable to wear all shift.

Features of the Nelson 656HVY hi-vis bib pants

Hi-vis yellow, ANSI Class E compliant. Bright yellow medium-weight 500 gsm PVC that meets ANSI Class E and EN 20471 Class 1, for jobs where hi-vis rain gear is required. Worn with an ANSI Class 2 or Class 3 top, it gives road crews, construction site workers and public works teams a Class 3 outfit.
Internal chest pocket. These hi-vis bib pants have a reinforced chest pocket on the inside. Your phone, ID or a small tool stays dry, close to your body and easy to reach.
Double-welded seams. Where there are seams, they’re welded twice. That outlasts single-weld garments and seals out water, which matters when you’re on your feet in the wet all day and a split seam means going home soaked.
Heavy-duty ankle snaps. Snap the legs closed over rubber boots or work boots so water can’t run in at the ankle, even when you’re standing in it or getting splashed. Handy for utility crews working in wet trenches.
2-inch marine-grade reflective tape. The tape is made for salt, sun and weather, and it meets the ANSI Class E and EN 20471 Class 1 requirements so drivers and machine operators see you.
Elastic waist and adjustable straps. The elastic waist gives when you bend, and the straps adjust with sturdy plastic buckles you can work with gloves on, which suits people on roads and construction sites who rarely take their gloves off.
Built for spray as well as rain. Welded PVC stands up to spray under pressure, so pressure washing contractors, construction crews and municipal crews stay dry whichever way the water comes.
Weight. 3.3 lb (1.5 kg), ± 1 oz (about 30 g) for smaller and larger sizes.

On the job: a tunnel project in Westerville, Ohio

Nelson 656HVY bib pants and Stormtex 248Y jackets were worn on the City of Columbus Big Walnut Sanitary Trunk Extension (Phase 2), a two-mile sewer tunnel near Westerville, Ohio. The tunnel boring machine cuts through bedrock 150 to 180 feet below ground. Two of the shafts were built by blasting, and the main shaft site runs around the clock when tunneling needs it.

The customer needed hi-vis rain gear that could hold up in that kind of demanding environment, and the 656HVY and 248Y are what the crew wore.

Ideal for

Road crews and highway workers: ANSI Class E hi-vis rain gear, worn with a Class 2 top
Pressure washing contractors: waterproof bib pants for spray from every direction
Municipal and public sector crews: parks, sanitation, utilities and public works, out in wet weather
Construction workers who need hi-vis rain gear on wet sites
Landscapers and groundskeepers who need waterproof cover through the wet season
Marine and dock workers who need hi-vis gear around boats and cargo

How ANSI Class E works

Class E is the ANSI/ISEA 107 category for hi-vis pants, bibs and overalls. A Class E garment isn’t meant to be worn on its own as your only hi-vis layer. Wear Class E bib pants with an ANSI Class 2 vest or jacket and the outfit counts as Class 3, the highest visibility class, with reflective tape around the legs as well as the torso. On a US site that requires ANSI, finish the rain gear outfit with an ANSI-rated top. For UK, European, Australian and New Zealand sites, the Stormtex 982TNS hi-vis vest shown with the 656HVY in the video above meets Class 3 in both EN ISO 20471 and AS/NZS 4602.1.

Hi-vis bib pants for the UK and Australia

In the UK and Europe, hi-vis clothing is rated to EN 20471 (EN ISO 20471), and the 656HVY meets EN 20471 Class 1. British crews often call these hi-vis bib and brace or hi-vis overalls rather than bib pants, and UK suppliers usually list them under waterproof workwear. In Australia and New Zealand the local standard is AS/NZS 4602.1, so if your site requires that rating, ask your safety officer whether EN 20471 or ANSI is accepted before you order.

The 656HVY is part of the Nelson range.

Why choose Stormline?

Since we were founded in 1966, Stormline has made and supplied wet weather and foul weather gear, from PVC bibs and jackets to hi-vis wet weather vests. Fishing, construction, forestry, farming, aquaculture, offshore: we’ve made gear for all of them. We’re a third-generation family business from Southland, New Zealand, where the weather is hard on gear, and we still design waterproof clothing with that in mind. More about Stormline, or browse all our commercial rain gear and industrial workwear.

Available in sizes XS to 5XL; see our sizing charts. Contact us for more information or for trade and wholesale orders.

Continue reading: heavy-duty rain gear for construction workers

Heavy-duty rain gear or medium weight for construction?

When the weather turns, the right rain gear is what lets a construction crew keep working. That doesn’t always mean heavy-duty rain gear: for most site and road work, medium-weight waterproof workwear like the 656HVY is easier to wear all day and tough enough for the job.

On a construction site or a road job, one downpour can soak a crew in minutes, and wet workers are slow, cold and distracted. Choosing well takes more than reading the label.

Check the materials and the seams

Cheap rain gear often uses decent fabric but leaks at the seams. On a construction site, rain gear has to survive the work as well as the weather. Heavy duty rain gear or medium weight, the checklist is the same: PVC, welded seams and hardware that won’t give out.

Comfort and movement

Rain gear nobody wants to wear doesn’t keep anyone dry. Bib pants that let you kneel, climb and bend without pulling are less tiring, and crews stay productive for longer. An elastic waist and adjustable straps, like those on the 656HVY, help the bib pants move with you.

Visibility

On road jobs, drivers have seconds to see you, and reflective tape on your legs shows them you are moving. Hi-vis bib pants with reflective tape in the right places keep you visible to co-workers, machine operators and passing traffic, and cut the risk of accidents. For more hi-vis options, see our hi-vis rain gear and safety workwear.

Choosing the right gear

When you’re buying rain gear for a construction crew, start with the industry standards and site rules that apply to you. Then weigh how long it’ll last and how it feels eight hours in. Our ultimate guide to construction rain gear covers this in more depth, or browse rain gear for building and construction and cleaning and power washing.

Frequently asked questions

Are the 656HVY bib pants ANSI compliant?

Yes. They conform to ANSI Class E and EN 20471 Class 1.

Can I wear these bib pants on their own on a road job?

Not as your only hi-vis layer. Class E garments are designed to be worn with a Class 2 or Class 3 top. Together they make a Class 3 outfit, with reflective tape on both the torso and the legs. Check what your site requires.

Are they good for pressure washing?

Yes. Unlike lightweight rain gear, the welded PVC handles spray from pressure washing or jet washing as well as rain, and the ankle snaps close over your boots.

Is there a pocket?

Yes, a reinforced chest pocket inside the bib, where your phone stays dry behind waterproof PVC.

How much do they weigh?

3.3 lb, give or take 1 oz depending on size. The 500 gsm PVC puts them in the medium-weight range.

Do you sell them in bulk for road crews or municipal teams?

Yes. Contact us about wholesale pricing on waterproof workwear for construction companies, utilities and municipal crews.

Additional information

Weight 1.5 kg
Dimensions 43 × 33 × 8 cm
Size

XS, S, M, L, XL, 2XL, 3XL, 4XL, 5XL
